Size and Weight – ขนาดและน้ำหนัก

• Dimensions: 3.85 inches (98 mm) by 3.85 inches (98 mm) by 6.6 inches (168 mm)
• Weight: 3.26 pounds (1.48 kg)1

Storage – พื้นที่เก็บข้อมูล

• 2TB hard drive
• 3TB hard drive

Wireless – ระบบไร้สาย

• IEEE 802.11a/b/g/n/ac
• Six-element beamforming antenna array
• Simultaneous dual-band 2.4GHz and 5GHz
• Radio output power: 32.5 dBm maximum (varies by country)
• Channels 1-11, 36-48, and 149-165 approved for use in the United States and Canada
• Channels 1-13, 36-64, and 100-140 approved for use in Europe and Japan
• Channels 1-13, 36-64, and 149-165 approved for use in Australia, Hong Kong, and New Zealand

Compatibility – ความเข้ากับ

• Interoperable with 802.11a, 802.11b, 802.11g, 802.11n, and 802.11ac-enabled Mac computers, iOS devices, Apple TV, Windows-based PCs, and other Wi-Fi devices
• NAT, DHCP, PPPoE, VPN Passthrough (IPSec, PPTP, and L2TP), DNS Proxy, IPv6 (6to4 and manual tunnels)

Security – ระบบความปลอดภัยและการเข้ารหัส

• Wi‑Fi Protected Access™ (WPA/WPA2)4
• WPA/WPA2 Enterprise4
• MAC address filtering
• NAT firewall
• 802.1X, PEAP, LEAP, TTLS, TLS, FAST
• Time-based access control

Software and Documentation – ซอฟต์แวร์และเอกสารที่ควรศึกษาเพิ่ม

• Printed documentation included
• AirPort Utility for Mac available for free download
• AirPort Utility for iOS available for free download
• Bonjour for Windows available for free download

Interfaces – พอร์ตและการเชื่อมต่อของอุปกรณ์

• Simultaneous dual-band 802.11ac wireless
• Gigabit Ethernet WAN port for connecting a DSL modem, cable modem, or Ethernet network
• USB 2 port for connecting a USB printer or hard drive
• Three Gigabit Ethernet LAN ports for connecting a computer, Ethernet hub, or networked printer
• Built-in power supply

Number of Users – รองรับผู้ใช้งานได้สูงสุด

• 50

Electrical and Environmental Requirements – ข้อมูลด้านไฟฟ้าและสภาพแวดล้อมที่ต้องการ

• 100-240V AC, 50-60Hz; input current: 1.5 amp
• Operating temperature: 32° to 95° F (0° to 35° C)
• Storage temperature: -13° to 140° F (-25° to 60° C)
• Relative humidity (operating): 20% to 80%, noncondensing
• Maximum operating altitude: 10,000 feet
• Maximum storage altitude: 15,000 feet

Agency Approval

• FCC Part 15 Class B, Canada RSS-210, EN 300-328, EN 301-489, EN 301 893, ARIB STD-T66, RCR STD-T33, AS/NZS 4268: 2003, UL 60950, CSA-C22.2 No. 60950, GB 4943.1-2011

System Requirements – ความต้องการของระบบ

Setup and Administration – การติดตั้งและการตั้งค่าภายในอุปกรณ์

• iPhone, iPad, or iPod touch with iOS 5 or later and AirPort Utility 1.3
• Mac with OS X Lion v10.7.5 or later and AirPort Utility 6.3

Wireless Device Access – อุปกรณ์ไร้สายที่สามารถเข้าถึงได้

• Any Wi‑Fi-enabled device that uses the 802.11a/b/g/n/ac specification

Shared Printing with a USB Printer – ระบบแชร์รวมถึง USB  ปริ้นเตอร์

• USB printer
• Mac with OS X v10.2.7 or later
• PC with Windows XP (SP3), Windows Vista (SP2), Windows 7 (SP1), or Windows 8

Shared USB Hard Drive

• Mac with OS X v10.4.8 or later
• PC with Windows XP (SP3), Windows Vista (SP2), Windows 7 (SP1), or Windows 8

Backup using Time Machine – การแบ็คอัปร่วมกับเครื่อง Mac os x

• Mac with OS X v10.5.7 or later

Meet the entire AirPort family.

AirPort Express makes it easy to set up or extend a wireless network anywhere. Need more speed? AirPort Extreme gives you up to 3x faster Wi-Fi. And for automatic wireless backup of up to 3TB of data, choose AirPort Time Capsule. Compare now

1. Weight varies by configuration and manufacturing process.
2. 1TB = 1 trillion bytes; actual formatted capacity less.
3. Based on an IEEE 802.11ac draft specification.
4. Support for Wi-Fi Protected Access (WPA/WPA2) requires OS X v10.3 or later or Windows XP with SP2 or later.

• Wireless Internet access requires a wireless-enabled computer or device, a base station or other access point, and Internet access (fees may apply).
